IPS-RB 380A

← Back to parts
IPS-RB 380A
Open larger image
IPS-RB 380A
Integrated Power System

IPS-RB 380A

Edge thickness 0.4-3mm Feed speed 18m/min Panel thickness 10-50mm Panel length ?140mm Panel width ?50mm Glue motor power 0.37kw Glue tank heating power 1.5kw End cutting motor power 0.55 kw*2 @18000rpm Fine trimming motor power 0.75 kw*2 @ 18000rpm Buffing motor power…

Manufacturer
Integrated Power System
Model
IPS-RB 380A
SKU
90a028607371
Category
Industrial Products
$15,750.00

Request a quote

Contact IPS to confirm availability and delivery.

Description

Edge thickness 0.4-3mm Feed speed 18m/min Panel thickness 10-50mm Panel length ?140mm Panel width ?50mm Glue motor power 0.37kw Glue tank heating power 1.5kw End cutting motor power 0.55 kw*2 @18000rpm Fine trimming motor power 0.75 kw*2 @ 18000rpm Buffing motor power 0.18 kw*2 @ 1400rpm Total motor power 7.0 kw Working pressure 0.7Mpa Extended support 550mm Outline size 3600*900*1500mm

Additional information

Weight 1480 lbs
Dimensions 150 × 48 × 70 in
