8750WDMT1A1FNSA040CA1M4G1Z5Q4

Description

ROSEMOUNT 8750W UTILITY MAGNETIC FLOW METER SYSTEM, 4 INCH
(DN100)
D Sensor Design Revision: Revision “D”
M Transmitter Class: Revision 4 Electronics
T Transmitter Mount: Integral Field Mount
1 Transmitter Power: AC Power Supply (90 to 250VAC, 50-60Hz)
A Transmitter Outputs: 4-20mA; Digital HART; Scalable Pulse
1 Conduit Entries: 1/2-14 NPT
F Sensor Style: Flanged
N Lining Material: Neoprene
S Electrode Material: 316L Stainless Steel
A Electrode Type: 2 Measurement Electrodes – Standard
C Flange Type and Material: Slip-On, Raised-Face, Carbon Steel
A1 Flange Rating: ASME B16.5, Class 150
Z5 Safety Approvals: US Approvals, Class I Div 2, Non-Incendive
and Dust for Non-Flammable Fluids
M4 Transmitter Display: Local Operator Interface
G1 Ground Ring: Ground Ring – 316L Stainless Steel (Qty 2)
Q4 Quality Certificate (Q4): Calibration Certificate per ISO 10474
3.1B / EN 10204 3.1.
