TM131-8JBBCCB1BX1AKAB2CA1AA1+NQZ1

Description

Endress+Hauser Intrinsically Safe Temperature Sensor iTHERM ModuLine TM131

8J Approval: ATEX IECEx II1/2G Ex ia IIC T6 Ga/Gb
B Thermowell: Thermometer with thermowell,
continuous, similar DIN43772 Form 2 G/F , 3 G/F
B Thermometer Design: Lagging, DIN43772 form 2G,
2F, 3G, 3F
CC Process/Thermowell Connection; Material: G1/2
male thread; 316L/316Ti
B1 Thermowell Diameter; Material: 9×1.25mm; 316L
B Tip Shape: Straight (DIN 43772 form 2/2G/2F)
X1 Immersion Length U: 300 mm (=<1000 mm) A Removable Neck Length E: 0mm, w/o neck K Lagging Length T: 145 mm A Sensor Type; Measuring Range; Material: 1xPt100 TF; -50...+400oC; 316L B Sensor Standard; Classification: IEC60751; class A, 3-wire 2C Electrical Connection: 4-20mA, 1-channel TMT71, head transmitter DIN B A1 Terminal Head; Material; Protect. Class: TA30A comfort flip cover; Alu; IP66/68 A Cable Entry Terminal Head: 1x M20x1.5 female thread A1 Device Model: 1 NQ >>Accessory Mounted: 1x cable gland Polyamide
Z1 >>Marking: Tagging (TAG), meta
Details
Low range value 50.000- °C
Upper range value 300.000 °C
Device 1
Metal label (71072708)
