PS6X – 223 3C9

Description

VEGA PULS 6X PS6X – 223 3C9 Radar sensor for continuous level measurement of all media
Generation : Second generation
Application : Standard
Radar technology : 80 GHz technology
Process fitting : Swivelling holder for bulk solids suitable for flange
EN1092-1, DN100 PN16, flat face, Form A / 316/316L
Antenna version : with lens antenna
Additional equipment : with rinsing connection
Material / Seal / Process temperature : PEEK / FKM (SHS FPM 70C3 GLT) / -40…+150°C
Housing / Protection : Plastic single chamber / IP66/IP67
Cable entry / Connection : M20x1.5 / Cable gland PA black (ø5-9mm), standard
Display, adjustment or radio module : Display/adjustment module PLICSCOM, with Bluetooth
Electronics : Two-wire 4 … 20 mA/HART
Explosion protection : for Ex-free area (CE, RCM, UKCA; in preparation: EAC)
Functional safety SIL (IEC 61508) : without
IT security (IEC 62443-4-2) : without
Overfill protection (WHG/VLAREM, in
preparation: KVU)
: without
Foodstuff/Pharmaceutical certificate : without
Ship approval (BV, RINA, ABS, DNV; in
preparation: CCS, ClassNK, LR)
: without
Second Line of Defense : without
Type label : of foil
Customer-specific settings : No
Max. measuring range : 393.700 ft
Operating instructions : EN – English
Number of operating instructions : 1
Min. process pressure in bar : -1.000
Max. process pressure in bar : 3.000
